X5900P (PCIe 5.0) - Xlenstor5 (PCIe 5.0)

X5900P

Next-Gen SCM eSSD

Extreme Performance

Ultra-Low Latency

Ultra-High Endurance

Overview

The Xlenstor5 series is purpose-built for enterprise-grade storage and write-intensive workloads. It delivers significantly higher endurance (DWPD), superior performance, and lower latency compared to TLC SSDs. Ideal for high-concurrency environments such as enterprise databases, supercomputing, AI training or inference, and cloud computing, it enhances storage efficiency and helps reduce overall TCO.

DapuStor Xlenstor U.2 (EN)_V1.2

Key Specifications

PCN (Product Code Name)	X5900P
Capacity (GB)	800	1600
Form Factor	U.2 15mm
Interface	PCIe 5.0 x 4, NVMe 2.0
128K Read Bandwidth (MB/s)	14000	14000
128K Write Bandwidth (MB/s)	9000	9000
4K Random Read KIOPS	3300	3300
4K Random Write KIOPS	1400	800
4K Random R/W Latency (μs)	21/7
4K Sequential R/W Latency (μs)	6/7
Typical Power	19	20
Idle Power	5
Endurance	120 DWPD	60 DWPD
MTBF	2.5 million hours
UBER	1 sector per 10^18 bits read
Warranty	5 years

Key Features

Faster Response, Lower Latency

SCM with Exceptional Performance

Ultra Endurance, Extended Lifespan

Advanced Features

The Xlenstor5 series delivers exceptional responsiveness with just 21 µs of random read latency and 7 µs of random write latency, meeting business demands.

Xlenstor5 Series SSD combines ultra-endurance, exceptional performance, and ultra-low latency, bridging the performance gap between DRAM and SSDs. Well-suited for write buffers and caching, it significantly enhances application performance.

Xlenstor5 Series SSDs leverage enterprise-grade FAST NAND, delivering up to 120 DWPD over five years to help reduce the maintenance costs. Designed for caching, they extend the lifespan of storage media in datacenters, making them ideal for hot data caching and high-frequency workloads, while offering both long-term reliability and cost efficiency.

● NVMe2.0
● OCP2.5 Compliance
● Supports NVMe-MI 1.2
● End-to-End Data Protection
● Enterprise Security Features
