The DapuStor® BootRAID series enterprise-grade RAID card is designed for server boot drive applications in enterprises and data centers. This series supports PCIe Gen4 (for both host and device interfaces) to meet the high-speed NVMe/SATA boot RAID card application requirements under the PCIe Gen4 platform.
The Flexraid6 series server boot RAID card, designed for enterprises and data centers, is built on DapuStor’s in-house developed DP808AL RAID card chip, featuring complete intellectual property rights.
• Host Interface: Supports PCIe 4.0x4, backward compatible with PCIe 3.0 • Host Protocols: Supports NVMe 2.0 and MI protocols with driver-free implementation • Device Interface: Supports NVMe 2.0 and SATA 3.0 • Performance: Sequential read/write bandwidth up to 7 GB/s; random read up to 1.7M IOPS
• PCIe HHHL Card • Compatible with NVMe SSDs and SATA SSDs • Supports M.2 SSDs (2230, 2242, 2260, 2280)
• Optional support for AES/RSA/SHA/TRNG encryption • Secure Boot
• Supports RAID 0/1 • S.M.A.R.T support • Disk hot-plug and hot-swap • Patrol read for media scanning and repairing • Online rebuild support • Check consistency for background data integrity
